Đầu ghi hình camera IP 16 kênh HIKVISION DS-7716NI-I4/16P

Video/ Audio Input

IP video input

16 channel

Two-way audio input

1-ch, RCA (2.0 Vp-p, 1kΩ)

Network

Incoming bandwidth

160Mbps

Outgoing bandwidth

256Mbps

Remote connection

128

Video/ Audio Output

HDMI output

1-ch, resolution: 4K (3840 x 2160)/ 60Hz, 4K (3840 x 2160)/ 30Hz, 1920 x 1080P/ 60Hz, 1600 x 1200/ 60Hz, 1280 x 1024/ 60Hz, 1280 x 720/ 60Hz, 1024 x 768/ 60Hz

Recording resolution

12MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

Audio Output

1-ch, RCA (Linear, 1kΩ)

VGA output

1920 x 1080p/ 60Hz, 1280 x 1024/ 60Hz, 1280 x 720/ 60Hz, 1024 x 768/60Hz

Audio output

1 channel, RCA (Linear, 1kΩ)

Decoding

Decoding format

H.265, H.264, MPEG4

Live view / Playback resolution

12MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

Capability

4 channel @ 4K or 16 channel @ 1080P

Hard Disk

SATA

4 SATA interface for 4 HDDs

Capacity

Up to 6TB for each disk HDD

External Interface

Network interface

2 RJ45 10/100/1000Mbps self-adaptive Ethernet interface

Serial interface

RS232 and RS485

USB interface

Front panel: 2 x USB 2.0

Rear panel: 1 x USB 3.0

Alarm in/out (Optional)

16/4

PoE interface

16 RJ45 10/100Mbps self-adaptive ethernet interfaces

Supported Standard

AF and AT

General

Power supply

100 ~ 240VAC

Consumption (Without hard disk)

≤ 20W (without enabling PoE)

Chassis

19-inch rack-mounted 1.5U chassis

Dimensions

445 x 390 x 70mm

Weight

≤ 5 kg
